using UnityEngine;
using System.Collections;
using System.Collections.Generic;
public class LSystem : MonoBehaviour {
GameObject m_Root = null;
const float FORWARD_DISTANCE = 2.0f;
class Pointer {
public Vector3 pos = Vector3.zero;
public Quaternion rot = Quaternion.identity;
}
string m_InitialString = "B";
string m_CurrentString = "";
Dictionary<string, string> m_RuleTable = null;
Pointer m_Pointer = null;
int m_Index = 0;
float m_Angle = 90;
void Awake () {
m_Pointer = new Pointer();
m_Pointer.pos = Vector3.zero;
m_Pointer.rot = Quaternion.identity;
m_Root = new GameObject("Tree");
m_Root.transform.position = Vector3.zero;
m_Root.transform.rotation = Quaternion.identity;
m_Angle = 60.0f;
m_RuleTable = new Dictionary<string, string>();
m_RuleTable.Add("F", "F");
m_RuleTable.Add("-", "-");
m_RuleTable.Add("+", "+");
m_RuleTable.Add("A", "B+A+B");
m_RuleTable.Add("B", "A-B-A");
m_RuleTable.Add("X", "X+YF");
m_RuleTable.Add("Y", "FX-Y");
string cmd = m_InitialString;
for(int i = 0; i < 6; ++i) {
m_CurrentString = "";
foreach(char s in cmd) {
m_CurrentString += m_RuleTable[s.ToString()];
}
cmd = m_CurrentString;
}
Debug.Log(m_CurrentString);
}
void Build (string command) {
foreach(char s in command) {
ParseCommand(s);
}
}
void ParseCommand(char s) {
switch(s) {
case 'F':
case 'A':
case 'B':
GameObject go = GameObject.Instantiate(Resources.Load("Branch")) as GameObject;
go.name = "Branch"+m_Index;
go.transform.position = m_Pointer.pos;
go.transform.rotation = m_Pointer.rot;
go.transform.parent = m_Root.transform;
Vector3 n = m_Pointer.rot*(FORWARD_DISTANCE*Vector3.up) + m_Pointer.pos;
m_Pointer.pos = n;
break;
case 'X':
case 'Y':
break;
case '-':
m_Pointer.rot = m_Pointer.rot * Quaternion.AngleAxis(m_Angle, Vector3.left);
break;
case '+':
m_Pointer.rot = m_Pointer.rot * Quaternion.AngleAxis(-m_Angle, Vector3.left);
break;
}
m_Index++;
}
void Start () {
Build(m_CurrentString);
}
void Update () {
}
}
